P13

p13

Frame ID: P13

Sample ID: Petroleum (Delayed) Coke

Magnification: As given

Illuminator: Vertical

Objective: 50x oil

Polarizer: In

Analyzer: In

Retarder Plate: In

Filter: None

Important Features: Granular coke

High Resolution Image (300 dpi)

Description: Coke derived from a petroleum feedstock that shows a fine-grained granular texture. Note the layering indicated by different grain sizes.
