P20

p20

Frame ID: P20

Sample ID: Petroleum (Delayed) Coke

Magnification: As given

Illuminator: Vertical

Objective: 50x oil

Polarizer: In

Analyzer: In

Retarder Plate: In

Filter: None

Important Features: Sponge coke

High Resolution Image (300 dpi)

Description: Coke derived from a petroleum feedstock that shows abundant pore structure. Note the flow texture in the coke cell walls.
