P02

p02

Frame ID: P02

Sample ID: Petroleum (Delayed) Coke

Magnification: As given

Illuminator: Vertical

Objective: 50x oil

Polarizer: In

Analyzer: In

Retarder Plate: In

Filter: None

Important Features: Needle coke

High Resolution Image (300 dpi)

Description: Typical needle coke derived from a petroleum feedstock. The parallel layers and linear fractures are distinctive and provide slip planes to relieve stress in the coke.
