P05

p05

Frame ID: P05

Sample ID: Petroleum (Delayed) Coke

Magnification: As given

Illuminator: Vertical

Objective: 50x oil

Polarizer: In

Analyzer: In

Retarder Plate: In

Filter: None

Important Features: Needle coke

High Resolution Image (300 dpi)

Description: Typical needle coke derived from a petroleum feedstock. The distinctive parallel layers and fractures are curved due to deformation in the plastic state.
