P32

p32

Frame ID: P32

Sample ID: Petroleum (Fluid) Coke

Magnification: As given

Illuminator: Vertical

Objective: 50x oil

Polarizer: In

Analyzer: In

Retarder Plate: In

Filter: None

Important Features: Circular structures

High Resolution Image (300 dpi)

Description: Circular structures formed by mesophase formed in the petroleum feedstock in the fluid coker.
