P38

p38

Frame ID: P38

Sample ID: Petroleum (Fluid) Coke

Magnification: As given

Illuminator: Vertical

Objective: 50x oil

Polarizer: In

Analyzer: In

Retarder Plate: In

Filter: None

Important Features: Fluid coke particles

High Resolution Image (300 dpi)

Description: Fluid coke particle formed in the fluid coker. Note the signs of agglomeration and the concentric fracture patterns.
